Product Features (1)50° high angle laser transmitter, with a maximum irradiation distance of up to 500 meters
(2)DSS digital step-by-step illumination angle control technology, 0.1 ° precision follow-up control
(3)GHT-II super HD floodlight source
(4)Independent photosensitive control to ensure accurate synchronization of the camera's color-to-black and laser switch
(5)The whole machine adopts super-strong aluminum alloy shell, IP65 protection, rain-proof, dust-proof, and can adapt to various harsh environments
Product Parameter | Projects | Nominal Value |
| Lens | 8mm-320mm 32X digital |
| Drone identification and tracking | ≥1.2km(Daylight), ≥1.0km (Night), Rotorcraft unmanned aerial vehicle with a wheelbase not exceeding 350mm |
| Video output | support 1920 × 1080@25fps Resolution not less than 1000TVL |
| illumination | Supports a minimum illumination of 0.05Lux in color, 0.004Lux in black and white, and F1.6 in aperture value |
| Laser lighting | 5W, 810nm military grade infrared laser, Illumination angle: 1°～20° |
| Head structure | a)Load: 50kg |
| Lens form | 25X F0.8-20MM ultra-short zoom patented technology |
| Horizontal maximum speed | ≥60°/S, pitch maximum speed ≥30°/S |
| Rotation angle | horizontal 360° continuous rotation, pitch: -40°-+75° |
| Safety Level | IP66 |
| Lightning surge protection | in accordance with the fourth level standard of GB/T17626.5 |
| Others | It is possible to view the preview images and recordings of unmanned aerial vehicles identified and tracked by photoelectric detection equipment through the platform |
| Equipped with image recognition algorithms, capable of identifying drones based on target features |
| Having good environmental adaptability, the equipment can work normally when the voltage changes within the range of AC24V ± 20% |
| Operation Temperature | -40℃-+65℃ |
Product Use It can automatically adapt to the brightness of the environment and automatically adjust the distance of the target and the size of the image, which is suitable for image acquisition in special cases.
