Product Introduction
F03B-CX wearable UAV detection and direction finding device is a professional equipment that can be carried by individual soldiers, can give real-time early warning to common civilian UAVs within 500-1500 meters, and can determine the direction of UAVs under simple operation. The equipment adopts advanced sensor technology and RF micro-assembly technology, with small size, simple operation, high sensitivity, low false alarm rate characteristics, and compared with the current similar products greatly reduced the volume and weight, reduce the individual soldier load, more practical value.

Product Advantage
● Small size, light weight, wearable design, suitable for individual soldiers
● High sensitivity, low false alarm rate
● Built-in acceleration sensor, no calibration, simple operation
● OLED display, parameters, status display intuitive
● Long battery life, perfect power management function

Product Parameter

Projects	Nominal Value	Remarks
Detection frequency range	1000-1500 MHz
	2400-2500 MHz
	5150-5950 MHz
Detect the signal type	OFDM/FM/WiFi
Detection distance	0.5 km ~ 1 km	In a general-view environment
Postback mode	4g/ 5g	Supports up to 200 equipment to form a grid to communicate with the command center
Response time	＜ 6s
The number of multi-target alerts	32
Power supply	3.7V/ 3.3Ah	Built-in lithium battery
Charging time	2 hours	From auto shutdown to maximum power
Battery life	≥ 8 hours	100% standby
	≥ 6 hours	25% active 75% standby
Protection class	Protection class IP65
Work environment	-40°C/+55°C
Volume	120×68×32mm
Weight	350g	Accessories such as chargers are not included

Product Use
(1) It can be linkage used with drone gun, navigation decoy and omnidirectional jamming equipment.
(2) A user can freely hold this equipment without fixed posture due to its built-in omnidirectional antenna.
