F04 is a passive/non-emitting stationary or vehicle-based RF detection product, delivering long range and highly accurate drone detection and tracking capabilities.
F04 adopts an integrated design, with a set of high-frequency and low-frequency signal detection antennas, RF signal receiving module, IF signal processing module, AI processing module and other functional modules.
F04 can quickly find UAV signals in the range of 300MHz-6GHz, and report the center frequency, bandwidth, azimuth, UAV model and other information of related signals to the command-and-control platform software. It adopts the latest AI technology and can discover and identify unknown UAV signals and update their signal characteristics into the database.
Product Features (1) Long Range Detection and Tracking-can detect and track the UAVs up to 8km
(2) Full Band Coverage- can detect and track any UAV signal within 300MHz- 6GHz signal range
(3) Accurate Identification-can automatically identify the type of UAVs with the build-in UAVs database
(4) AI Enabling-can detect unknown UAVs and update to the database
(5) Self position-with build-in electronic compass
Performance Parameter
· Frequency range: 300MHz- 6GHz
· Detection range: ≥8km
· Azimuth coverage: 360°
· Elevation coverage: -5°- 55° (5.5km)/ -5°- 40°(8km)
· Power supply: AC 220V/DC 24V
· Operating temperature: -40℃/65℃
· Storage temperature: -45℃/70℃
· IP rating: IP65
· Dimensions(W*D*H): 650*650*450mm
· Weight: ≤25kg
F04 UAV Detector
