GNSS spoofer is the generation and transmission of fake GNSS signals, with the aim to lead a GNSS receiver astray, possibly without the GNSS receiver being aware of the attack. GNSS spoofer overtake the rogue drone's navigation link and manipulate the information within it. The spoofer sends a new signal to the drone, replacing the communication with GNSS satellites, such as GPS or GLONASS. By dynamically altering the GNSS coordinates in real-time, the drone can be controlled by the spoofer and flown to a safe zone.



Product Features
(1) Support setting the no-fly zone function: set the coordinates of the no-fly zone, so that the drone that has not taken off within the effective deception distance cannot take off and the drone in the air will automatically land
(2) Support directional displacement function: set the displacement direction and displacement speed of the drone within the effective range
(3) The device emits analog signals to make the drone move in a straight line or in a circle. The movement speed, center and diameter can be set
(4) It can be linked with radar or radio detection equipment to achieve directional displacement or forced landing of UAVs and the strategy can be configured
(5) Cooperate with radar to capture drones in the coverage area and guide them to a safe area specified by the user
(6) The system provides three antennas: one is used to receive ephemeris and the other two are used to transmit analog navigation signals
(7) When linked with the radar, if the 3D position of the target is known (the radar provides a continuous position), the coordinate positioning accuracy of the spoofing signal is better than 20 meters
(8) It can simulate the transmission of GLONASS/GPS/BDS navigation signals, and the analog coordinate position can be set
(9) Working hours: unattended can work 24 hours
(10) Support ephemeris download and load function
(11) Signal transmission can be turned on and off remotely, and radio transmission power can be adjusted remotely



Product Parameter
 · Spoofing bands: BDS B1/B2, GPS L1/L2, GLONASS L1/L2, Galileo E1
 · Spoofing range: ≥ 50 km
 · Azimuth coverage: 360°
 · Elevation coverage: -10°- 70°
 · Power supply: AC 220 V
 · Operating temperature: -20℃/65℃
 · Storage temperature: -25℃/70℃
 · IP rating: IP65
 · Dimensions(W*D*H): 480 * 480 * 190 mm
 · Weight: ≤ 35 kg
